Er zal nr uit stapfenomeen zijn en geen extra koppelt controle terug wordt vereist, met uitstekende statische en dynamische stabiliteit.
Slechts wanneer het moet roteren zal het elektriciteit verbruiken, en de machtsconsumptie op reservewijze is zeer laag, besparend energie.
Eigenschappen:
Stapengel |
1.8 ° |
Framgrootte |
57 mm |
Aantal Fase |
tweefasen |
Geschatte Stroom |
2.0 A |
Het houden van Torsie |
1200 mN.m |
Weerstand |
1,4 ohm |
Inductantie |
5.0 MH |
Rotorinertie |
260 g-cm ² |
Motorgewicht |
0,6 kg |
Aantal lood |
4 |
Verbinding |
Bipolair |
Staphoek: 1.8°
Maximumtemperatuur: 80°C maximum
Omgevingstemperatuur: -20 °C aan 50°C
Opslagtemperatuur -20: °C aan 100°C
Vochtigheidswaaier (%): 85% of non-condensing minder,
De Isolatie van de magneetdraad: Klasse B 130 gr.C.
Isolatieweerstand: 100M Ohm bij 500 VDC
Diëlektrische Sterkte: 500 VDC voor 1 min
Model | Het houden van Torsie | Staphoek | Lengte | Type van Schacht | Geschatte Stroom |
57SHD4013-21B | 0.6N.m | 1.8° | 41mm | D schacht-21mm | 1.0A |
57SHD4415-21B | 1.1N.m | 1.8° | 54mm | D schacht-21mm | 3.0A |
57SHD4816-21B | 2.0N.m | 1.8° | 76mm | D schacht-21mm | 3.0A |
57SHD4913-21B | 2.5N.m | 1.8° | 83mm | D schacht-21mm | 3.0A |
57SHD4934-20B | 3.0N.m | 1.8° | 100mm | D schacht-20mm | 3.0A |
